Power Amplifier MB8000
The classic Chevin A-Series amplifier is built in a steel and aluminum housing incorporating lateral Mosfets and the Chevin Power Supply. This combination produces the traditional Chevin sound. The amplifier is designed for driving sub-woofers.
Technical Specification
| Nominal Output Power (1 kHz, 1 % THD) | |
| into 8 Ω | 2000 W |
| into 4 Ω | 4000 W |
| into 2 Ω | 8000 W |
| THD 1 kHz, 8 Ω | < 0,05 % |
| Frequency Response - by 10 dB below nominal power |
20 Hz - 20 kHz +0 /-1 dB 20 Hz - 50 kHz +0 /-1 dB |
| Damping Factor - 8 Ω, 1kHz | 400 |
| S/N Ratio S/N Ratio „A“ weighted |
> 95 dB > 112 dB |
| Input Sensitivity - by nominal power / 8 Ω | 1,0 V |
| Input Impedance balanced | 10 kΩ |
| Slew Rate - 8 Ω | 50 V / µS |
| Controls | Front: Mains switch + volume control |
| Indicators | POWER: green LED OUTPUT VOLTS level: green LED LIMITER: red LED |
| Cooling | Variable speed fan |
| Protection | |
| Clipping, Load mismatch | soft, dynamic linear |
| Shorted output, DC or RF at output | immediate |
| Power | 230V AC 50Hz |
| Dimensions/Weight | 132 x 483 x 402,5 mm (3u) |
| Weight | 14kg |
©2010 Chevin Research. Product design and specifications may change without prior notice
Attachments: PDF document 224 Kb
